Image preview - the first page of the document
ixth230n085t_ixtq230n085t


>> Download ixth230n085t_ixtq230n085t documenatation <<

Text preview - extract from the document
                                        Preliminary Technical Information

TrenchMVTM                                          IXTH230N085T                                VDSS             = 85  V
Power MOSFET                                        IXTQ230N085T                                ID25             = 230 A
                                                                                                RDS(on)           4.4 m
N-Channel Enhancement Mode
                                                                                               TO-247 (IXTH)
Avalanche Rated




Symbol        Test Conditions                                      Maximum Ratings
                                                                                                         G
VDSS          TJ = 25
