Image preview - the first page of the document
ixth6n150


>> Download ixth6n150 documenatation <<

Text preview - extract from the document
                                           Advance Technical Information

High Voltage                                            IXTH6N150                       VDSS       =        1500V
Power MOSFET                                                                            ID25       =        6A
                                                                                        RDS(on)             3.5
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode
                                                                                        TO-247

Symbol       Test Conditions                                Maximum Ratings
VDSS         TJ = 25
