2N5655, 2N5657

Plastic NPN Silicon
High-Voltage Power
Transistor
  These devices are designed for use in line-operated equipment such
as audio output amplifiers; low-current, high-voltage converters; and                                       http://onsemi.com
AC line relays.

Features                                                                                              0.5 AMPERE
                                                                                                 POWER TRANSISTORS
