MJ15001 (NPN),
MJ15002 (PNP)

Complementary Silicon
Power Transistors
  The MJ15001 and MJ15002 are EpiBaset power transistors
designed for high power audio, disk head positioners and other linear                              http://onsemi.com
applications.

Features                                                                                        20 AMPERE
