       2N6764, JANTX2N6764, JANTXV2N6764                           2N6768, JANTX2N6768, JANTXV2N6768
       2N6766, JANTX2N6766, JANTXV2N6766                           2N6770, JANTX2N6770, JANTXV2N6770


JANTX, JANTXV POWER MOSFET IN TO-204 PACKAGE,
QUALIFIED TO MIL-PRF-19500/543

100V Thru 500V, Up to 38A, N-Channel,
Enhancement Mode MOSFET Power Transistor
