        2N7218, JANTX2N7218, JANTXV2N7218                      2N7221, JANTX2N7221, JANTXV2N7221
        2N7219, JANTX2N7219, JANTXV2N7219                      2N7222, JANTX2N7222, JANTXV2N7222


JANTX, JANTXV POWER MOSFET IN TO-254AA PACKAGE,
QUALIFIED TO MIL-PRF-19500/596

100V Thru 500V, Up to 28A, N-Channel,
MOSFET Power Transistor, Repetitive Avalanche Rated
