                              OM120L60SB                                                OM90L120SB
       Preliminary Data Sheet OM100F60SB                                                OM70F120SB

IGBTS IN HERMETIC ISOLATED POWER
BLOCK PACKAGES


                           High Current, High Voltage 600V And 1200V,
                           Up To 150 Amp IGBTs With FRED Diodes
