Image preview - the first page of the document



>> Download dta143e documenatation <<

Text preview - extract from the document

                                                       DTA143EE/DTA143EUA/DTA143ECA
                                                               DTA143EKA/DTA143ESA
                                                                               Digital Transistor(PNP)

Features
1) Built-in bias resistors enable the configuration of an inverter circuit
   without connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation
   to allow negative biasing of the input. They also have the advantage of
   almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making
    device design easy.


PIN CONNENCTIONS AND MARKING

 DTA143EE                                                  DTC114EUA
                                                           DTA143EUA




                                                           SOT-323

 SOT-523       Addreviated symbol: 13                                          Addreviated symbol: 13



 DTA143EKA                                                 DTA143ECA




                                                           SOT-23
 SOT-23-3L
                   Addreviated symbol: 13                                  Addreviated symbol: 13




 DTA143ESA




   TO-92S
                                                       DTA143EE/DTA143EUA/DTA143ECA
                                                               DTA143EKA/DTA143ESA
                                                                                   Digital Transistor(PNP)
Absolute maximum ratings(Ta=25)
                                                            Limits (DTA143E )
     Parameter         Symbol                                                                                      Unit
                                            E          UA             KA                CA             SA
   Supply voltage          VCC                                        -50                                           V
    Input voltage          VIN                                      -30~10                                          V
                               IO                                    -100
   Output current                                                                                                  mA
                         IC(MAX)                                     -100
 Power dissipation         Pd              150                       200                               300         mW
      Junction
                               Tj                                    150
    temperature
Storage temperature       Tstg                                      -55~150
Electrical characteristics (Ta=25)
     Parameter         Symbol        Min.        Typ         Max.           Unit                 Conditions
                        VI(off)                              -0.5                            VCC=-5V ,IO=-100
