Image preview - the first page of the document



>> Download dta143z documenatation <<

Text preview - extract from the document

                                                       DTA143ZE/DTA143ZUA/DTA143ZCA/
                                                                DTA143ZKA/DTA143ZSA
                                                                            Digital Transistor (PNP)



Features
1) Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation to allow
   negative biasing of the input. They also have the advantage of almost
   completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making device design
   easy.



PIN CONNENCTIONS AND MARKING

 DTA143ZE                                                   DTA143ZUA




                                                            SOT-323         Addreviated symbol: 113
 SOT-523       Addreviated symbol: E13



 DTA143ZKA                                                  DTA143ZCA
                                                            DTA114ECA




 SOT-23-3L
                                                            SOT-23            Addreviated symbol: E13
                 Addreviated symbol: E13



 DTA143ZSA




 TO-92S
                                                            DTA143ZE/DTA143ZUA/DTA143ZCA/
                                                                     DTA143ZKA/DTA143ZSA
                                                                                  Digital Transistor (PNP)
Absolute maximum ratings(Ta=25)
                                                               Limits (DTA143Z )
       Parameter           Symbol                                                                                 Unit
                                                E             UA             KA            CA            SA
    Supply voltage                VCC                                       -50                                    V
     Input voltage                VIN                                      -30~5                                   V
                                   IO                                      -100
    Output current                                                                                                mA
                               IC(MAX)                                     -100
  Power dissipation               Pd            150                         200                         300       mW
Junction temperature               Tj                                      150
 Storage temperature              Tstg                                    -55~150
Electrical characteristics (Ta=25)
     Parameter         Symbol            Min.         Typ      Max.           Unit               Conditions
                        VI(off)                                    -0.5                      VCC=-5V ,IO=-100
