Image preview - the first page of the document



>> Download dta144e documenatation <<

Text preview - extract from the document

                                                         DTA144EE/DTA144EUA/DTA144ECA
                                                                DTA144EKA/DTA144ESA
                                                                               Digital Transistor(PNP)

Features
1.   Built-in bias resistors enable the configuration of an inverter
     circuit without connecting external input resistors
     (see equivalent circuit).
2.   The bias resistors consist of thin-film resistors with complete
      isolation to allow negative biasing of the input.They also
      have the advantage of almost completely eliminating parasitic effects.

3.   Only the on/off conditions need to be set for operation,
      making device design easy.


PIN CONNENCTIONS AND MARKING



     DTA144EE                                              DTA144EUA




     SOT-523        Addreviated symbol: 16                 SOT-323        Addreviated symbol: 16



     DTA144EKA
                                                           DTA144ECA




     SOT-23-3L                                             SOT-23
                        Addreviated symbol: 16                                 Addreviated symbol: 16




     DTA144ESA




      TO-92S
                                                           DTA144EE/DTA144EUA/DTA144ECA
                                                                  DTA144EKA/DTA144ESA
Absolute maximum ratings(Ta=25)                                                         Digital Transistor(PNP)
                                                                Limits (DTA144E           )
       Parameter        Symbol                                                                                            Unit
                                            E              UA               KA                CA             SA
Supply voltage            VCC                                               -50                                            V
Input voltage              VIN                                            -40~+10                                          V
                               IO                                           -30
Output current                                                                                                            mA
                         IC(MAX)                                           -100
Power dissipation          Pd              150                             200                              300           mW
Junction temperature           Tj                                          150
Storage temperature       Tstg                                            -55~150
Electrical characteristics (Ta=25)
     Parameter         Symbol       Min.         Typ             Max.         Unit                      Conditions
                         VI(off)                                  -0.5                               VCC=-5V ,IO=-100
