Image preview - the first page of the document
>> Download dtc143z documenatation <<
Text preview - extract from the document
DTC143ZE/DTC143ZUA/DTC143ZCA
DTC143ZKA/DTC143ZSA
Digital Transistor(NPN)
Features
1. Built-in bias resistors enable the configuration of an inverter circuit without
connecting external input resistors (see equivalent circuit).
2. The bias resistors consist of thin-film resistors with complete isolation to
allow negative biasing of the input. They also have the advantage of almost
completely eliminating parasitic effects.
3. Only the on/off conditions need to be set for operation, making
device design easy.
PIN CONNENCTIONS AND MARKING
DTC143ZE DTC143ZUA
SOT-523 Addreviated symbol: E23 SOT-323 Addreviated symbol: E23
DTA114ECA
DTC143ZKA DTC143ZCA
SOT-23
SOT-23-3L
Addreviated symbol: E23 SOT-23 Addreviated symbol: E23
DTC143ZSA
TO-92S
DTC143ZE/DTC143ZUA/DTC143ZCA
DTC143ZKA/DTC143ZSA
Digital Transistor(NPN)
Absolute maximum ratings(Ta=25)
Limits (DTC143Z )
Parameter Symbol Unit
E UA CA KA SA
Collector-base voltage V(BR)CBO 50 V
Collector-emitter voltage V(BR)CEO 50 V
Emitter-base voltage V(BR)EBO 5 V
Collector current IC 100 mA
Collector Power dissipation PC 150 200 300 mW
Junction temperature Tj 150
Storage temperature Tstg -55~150
Electrical characteristics (Ta=25)
Parameter Symbol Min. Typ Max. Unit Conditions
VI(off) 0.5 VCC=5V ,IO=100A
Input voltage V
VI(on) 1.3 VO=0.3V ,IO=5 mA
Output voltage VO(on) 0.1 0.3 V IO/II=5mA/0.25mA
Input current II 1.8 mA VI=5V
Output current IO(off) 0.5 A VCC=50V ,VI=0
DC current gain GI 80 VO=5V ,IO=10mA
Input resistance R1 3.29 4.7 6.11 K
Resistance ratio R2/R1 8 10 12
Transition frequency fT 250 MHz VCE=10V ,IE=-5mA,f=100MHz
