Image preview - the first page of the document



>> Download dtc114y documenatation <<

Text preview - extract from the document

                                                      DTC114YE/DTC114YUA/DTC114YCA
                                                              DTC114YKA/DTC114YSA
                                                                            Digital Transistor(NPN)


Features
1.   Built-in bias resistors enable the configuration of an inverter circuit without
     connecting external input resistors(see equivalent circuit).
2.   The bias resistors consist of thin-film resistors with complete isolation to allow
     negative biasing of the input. They also have the advantage of almost completely
     eliminating parasitic effects.
3.   Only the on/off conditions need to be set for operation, making device design easy.


PIN CONNENCTIONS AND MARKING

 DTC114YE                                                 DTC114YUA




     SOT-523       Addreviated symbol: 64                   SOT-323       Addreviated symbol: 64


                                                          DTA114ECA
                                                          DTC114YCA
 DTC114YKA


   SOT-23
 SOT-23-3L
                     Addreviated symbol: 64               SOT-23        Addreviated symbol: 64



 DTC114YSA




 TO-92S
                                                           DTC114YE/DTC114YUA/DTC114YCA
                                                                   DTC114YKA/DTC114YSA
                                                                                    Digital Transistor(NPN)
Absolute maximum ratings(Ta=25)
                                                                        Limits (DTC114Y )
                Parameter               Symbol                                                                      Unit
                                                          E       UA           KA           CA         SA
Supply voltage                            VCC                                  50                                    V
Input voltage                             VIN                                -6to+40                                 V
                                           IO                                  70                                   mA
Output current
                                         IC(Max.)                             100                                   mA
Power dissipation                          PC             150                 200                      300          mW
Junction temperature                       Tj                                 150

Storage temperature                       Tstg                             -55 to+ 150

Electrical characteristics (Ta=25)
     Parameter              Symbol     Min.         Typ         Max.         Unit                  Conditions
                             VI(off)                              0.3                            VCC=5V ,IO=100
