Image preview - the first page of the document
>> Download 2n3055a_mj2955a_mj15015_mj15016 documenatation <<
Text preview - extract from the document
MOTOROLA Order this document
by 2N3055A/D
SEMICONDUCTOR TECHNICAL DATA
NPN
Complementary Silicon 2N3055A
High-Power Transistors
. . . PowerBase complementary transistors designed for high power audio, stepping
MJ15015*
MJ2955A
motor and other linear applications. These devices can also be used in power
switching circuits such as relay or solenoid drivers, dc◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
