Image preview - the first page of the document



>> Download mjd44e3r documenatation <<

Text preview - extract from the document

MOTOROLA                                                                                                  Order this document
                                                                                                                by MJD44E3/D
SEMICONDUCTOR TECHNICAL DATA



                                                                                                    MJD44E3*
Darlington Power Transistor                                                                          *Motorola Preferred Device


DPAK For Surface Mount Application                                                                   NPN DARLINGTON
                                                                                                          SILICON
. . . for general purpose power and switching output or driver stages in applications               POWER TRANSISTOR
such as switching regulators, converters, and power amplifiers.                                        10 AMPERES
