Image preview - the first page of the document
>> Download mjd44h11_mjd45h11 documenatation <<
Text preview - extract from the document
MOTOROLA Order this document
by MJD44H11/D
SEMICONDUCTOR TECHNICAL DATA
NPN
MJD44H11 *
Complementary Power PNP
Transistors MJD45H11 *
DPAK For Surface Mount Applications *Motorola Preferred Device
. . . for general purpose power and switching such as output or driver stages in
applications such as switching regulators, converters, and power amplifiers. SILICON
POWER TRANSISTORS
