Image preview - the first page of the document
>> Download 2n4091_2n4092_2n4093 documenatation <<
Text preview - extract from the document
TECHNICAL DATA
N-CHANNEL J-FET
Qualified per MIL-PRF-19500/431
Devices Qualified Level
JANTX
2N4091 2N4092 2N4093
JANTXV
ABSOLUTE MAXIMUM RATINGS (TA = +250C unless otherwise noted)
Parameters / Test Conditions Symbol Value Units
Gate-Source Voltage VGS -40 V
Drain-Source Voltage VDS 40 V
Drain-Gate Voltage VDG 40 V
Gate Current IG 10 mAdc
Power Dissipation (1) TA = +250C PT 0.36 W
Operating Junction Tj -65 to +175 0
C TO-18*
Operating Storage Temperature Range Tstg -65 to +200 0
C (TO-206AA)
(1) Derate linearly 2.4 mW/0C for TA > 250C.
*See appendix A for
package outline
ELECTRICAL CHARACTERISTICS (TC = +250C unless otherwise noted)
PARAMETERS / TEST CONDITIONS Symbol Min. Max. Units
Gate-Source Breakdown Voltage
VDS = 0, IG = -1.0 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
