Image preview - the first page of the document
2n5581_2n5582


>> Download 2n5581_2n5582 documenatation <<

Text preview - extract from the document
                                                                            TECHNICAL DATA

NPN SILICON SWITCHING TRANSISTOR
Qualified per MIL-PRF-19500/423

Devices                                                                                       Qualified Level
                                                                                                    JAN
2N5581                                         2N5582                                              JANTX
                                                                                                  JANTXV




MAXIMUM RATINGS
             Ratings                              Symbol       Value          Unit
 Collector-Emitter Voltage                         VCEO           50          Vdc
 Collector-Base Voltage                            VCBO           75          Vdc
 Emitter-Base Voltage                              VEBO           6.0         Vdc
 Collector Current                                  IC            800         mAdc
 Total Power Dissipation     @ TA = 250C (1)                      0.5          W
                                                     PT
                             @ TC = 250C (2)                      2.0          W                   TO-46*
                                                                               0
 Operating & Storage Junction Temperature Range   Top, Tstg   -55 to +200       C                (TO-206AB)
1) Derate linearly 2.86 mW/0C for TA > 250C
2) Derate linearly 11.43 mW/0C for TC > 250C
                                                                                            *See appendix A for
                                                                                            package outline


ELECTRICAL CHARACTERISTICS (TA = 250C unless otherwise noted)
                             Characteristics                       Symbol            Min.      Max.         Unit
OFF CHARACTERISTICS
 Collector-Emitter Breakdown Voltage
                                                                   V(BR)CEO           50                     Vdc
  IC = 10 mAdc
 Collector-Base Cutoff Current
  VCB = 60 Vdc                                                       ICBO                        10         Adc
  VCB = 75 Vdc                                                                                   10
