Image preview - the first page of the document

>> Download 2stp535fp documenatation <<

Text preview - extract from the document

                                                       NPN power Darlington transistor

   Monolithic Darlington transistor with integrated
   antiparallel collector-emitter diode
   Very high DC current gain

   Electronic ignition                                                                   2
   AC-DC motor control
   Alternator regulator

Description                                             Figure 1.   Internal schematic diagram
The 2STP535FP is a planar NPN power
transistor in monolithic Darlington configuration
mounted in TO-220FP fully isolated package.

                                                                         R typ. = 75

Table 1.      Device summary
       Order code                  Marking                   Package                    Packaging

       2STP535FP                 2STP535FP                  TO-220FP                      Tube

August 2009                                  Doc ID 16132 Rev 1                                        1/8
Electrical ratings                                                              2STP535FP

1           Electrical ratings

            Table 2.     Absolute maximum ratings
             Symbol                            Parameter             Value          Unit

               VCBO    Collector-base voltage (IE = 0)                180            V
               VCEO    Collector-emitter voltage (IB = 0)             180            V
               VEBO    Emitter-base voltage (IC = 0)                   5             V
                IC     Collector current                               8             A
               ICM     Collector peak current (tp < 5 ms)             15             A
                IB     Base current                                    1             A
               Ptot    Total dissipation at Tc  25
