Image preview - the first page of the document
>> Download buh515fp documenatation <<Text preview - extract from the document BUH515FP
HIGH VOLTAGE FAST-SWITCHING
NPN POWER TRANSISTOR
s HIGH VOLTAGE CAPABILITY
s FULLY MOLDED ISOLATED PACKAGE
s 2000 V DC ISOLATION (U.L. COMPLIANT)
APPLICATIONS:
s HORIZONTAL DEFLECTION FOR COLOUR
TV AND MONITORS
s SWITCH MODE POWER SUPPLIES 3
2
1
DESCRIPTION TO-220FP
The BUH515FP is manufactured using
Multiepitaxial Mesa technology for cost-effective
high performance and uses a Hollow Emitter
structure to enhance switching speeds.
The BUH series is designed for use in horizontal
deflection circuits in televisions and monitors. INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS
Symbol Parameter Value Uni t
V CBO Collector-Base Voltage (IE = 0) 1500 V
V CEO Collector-Emitter Voltage (I B = 0) 700 V
V EBO Emitter-Base Voltage (I C = 0) 10 V
IC Collector Current 8 A
I CM Collector Peak Current (tp < 5 ms) 12 A
IB Base Current 5 A
I BM Base Peak Current (t p < 5 ms) 8 A
o
P t ot Total Dissipation at T c = 25 C 38 W
o
T stg St orage Temperature -65 to 150 C
o
Tj Max. Operating Junction Temperature 150 C
April 1998 1/7
BUH515FP
THERMAL DATA
o
R t hj-ca se Thermal Resistance Junction-case Max 3.3 C/W
ELECTRICAL CHARACTERISTICS (Tcase = 25 oC unless otherwise specified)
Symb ol Parameter Test Cond ition s Min. Typ . Max. Un it
I CES Collector Cut-off V CE = 1500 V 0.2 mA
o
Current (V BE = 0) V CE = 1500 V Tj = 125 C 2 mA
I EBO Emitter Cut-off Current V EB = 5 V 100
