Image preview - the first page of the document



>> Download stw30nm60nd_stp30nm60nd_stf30nm60nd_sti30nm60nd_stb30nm60nd documenatation <<

Text preview - extract from the document

                                                                                              STx30NM60ND
           N-channel 600 V, 0.11 , 25 A FDmeshTM II Power MOSFET
            (with fast diode) TO-220, TO-220FP, D2PAK, I2PAK, TO-247

Features
                    VDSS @TJ       RDS(on)
       Type                                        ID
                      max           max
                                                                   2               3                                                 3
STB30NM60ND                                       25 A             I PAK        12                                               2
                                                                                                                             1
STI30NM60ND                                       25 A                                                          TO-247

STF30NM60ND            650 V        0.13         25 A(1)
                                                                                                          3
STP30NM60ND                                       25 A                                         2      1
                                                                                              D PAK
STW30NM60ND                                       25 A
1. Limited only by maximum temperature allowed
                                                                                          3
                                                                                                                                     3
   The world's best RDS(on) in TO-220 amongst                      TO-220         1
                                                                                      2
                                                                                                                                 2
                                                                                                                TO-220FP     1
   the fast recovery diode devices
   100% avalanche tested
   Low input capacitance and gate charge
                                                               Figure 1.     Internal schematic diagram
   Low gate input resistance
   Extremely high dv/dt and avalanche
   capabilities

Application
   Switching applications

Description
The FDmeshTM II series belongs to the second
generation of MDmeshTM technology. This
revolutionary Power MOSFET associates a new
vertical structure to the company's strip layout
and associates all advantages of reduced on-
resistance and fast switching with an intrinsic fast-          It is therefore strongly recommended for bridge
recovery body diode.                                           topologies, in particular ZVS phase-shift
                                                               converters.
Table 1.      Device summary
       Order codes                     Marking                         Package                                Packaging

      STB30NM60ND                     30NM60ND                          D
