Image preview - the first page of the document



>> Download stl72 documenatation <<

Text preview - extract from the document

                                                                                                                    STL72

                                    High voltage fast-switching NPN power transistor

Features
    High voltage capability
    Low spread of dynamic parameters
    Very high switching speed

Application
    Compact fluorescent lamps (CFLs)

Description                                                                     TO-92                        TO-92AP
The device is manufactured using high voltage
multi epitaxial planar technology for high switching
speeds and high voltage capability. It uses a
cellular emitter structure with planar edge                          Figure 1.        Internal schematic diagram
termination to enhance switching speeds while
maintaining the wide RBSOA.
The STL series is designed for use in compact
fluorescent lamps.




Table 1.        Device summary
       Order codes (1)                     Marking (2)                       Package                          Packaging

            STL72                        L72 L or L72 H                        TO-92                             Bulk
           STL72-AP                      L72 L or L72 H                      TO-92AP                          Ammopack
         STL72G-AP                     L72G L or L72G H                      TO-92AP                          Ammopack
1. The letter "G" in the order code suffix identifies the product as ECOPACK
