Image preview - the first page of the document



>> Download 2sd863 documenatation <<

Text preview - extract from the document

Ordering number:575D


                                                                              PNP/NPN Epitaxial Planar Silicon Transistors

                                                                                                2SB764/2SD863
                                                        Voltage Regulator, Relay Lamp Driver
                                                           Electrical Equipment Applications


                                                                     Package Dimensions
                                                                     unit:mm
                                                                     2006A
                                                                                              [2SB764/2SD863]




                                                                                                   EIAJ : SC-51               B : Base
( ) : 2SB764
                                                                                                   SANYO : MP                 C : Collector
Specifications                                                                                                                E : Emitter

Absolute Maximum Ratings at Ta = 25
