Image preview - the first page of the document



>> Download 2sa1020 documenatation <<

Text preview - extract from the document

                                                                                                               2SA1020
                                                                                                         -2A, -50V
                     Elektronische Bauelemente                                              PNP Plastic Encapsulated Transistor

                                                               RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen & lead-free

                                                                                                                                TO-92MOD
 FEATURES
                                                                                                                            N
              Power amplifier applications
                                                                                                               G                       H
                                                                                                                                                  Emitter
                                                                                                                                                  Collector
                                                                                                                                                  Base
 CLASSIFICATION OF hFE(1)                                                                                 M
                                                                                                                            L          J
         Product-Rank              2SA1020-O     2SA1020-Y                                                                  A                    D
            Range                     70-140       120-240

                                                                                                                                       B


                                                                                                               K
                                                                                                               E                                 F
                                                                                                                                       C
                                                                               Collector


                                                                                                               REF.
                                                                                                                           Millimeter
                                                                                                                         Min.     Max.
                                                                                                                                            REF.
                                                                                                                                                        Millimeter
                                                                                                                                                      Min.     Max.
                                                               Base                                             A        5.50     6.50       H        1.70     2.05
                                                                                                                B        8.00     9.00       J        2.70     3.20
                                                                                                                C        12.70    14.50      K        0.85     1.15
                                                                                                                D        4.50     5.30       L          1.60 Max
                                                                               Emitter                          E        0.35     0.65       M        0.00     0.40
                                                                                                                F        0.30     0.51       N           4.00 Min
                                                                                                                G          1.50 TYP.




 ABSOLUTE MAXIMUM RATINGS (TA = 25
