Image preview - the first page of the document



>> Download 2sa1298 documenatation <<

Text preview - extract from the document

                                                                                                     2SA1298
                                                                                                  -0.8A , -35V
                     Elektronische Bauelemente                                    PNP Silicon Plastic Encapsulated Transistor

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


                                                                                                                                 SOT-23
 FEATURES
    Low Frequency Power Amplifier Application
                                                                                                                 A
    Power Switching Applications                                                                                     L
                                                                                                                 3
                                                                                                                                                           3

                                                                                                              Top View           C B
 CLASSIFICATION OF hFE (1)                                                                                                                    1
                                                                                                          1              2
        Product-Rank            2SA1298-O         2SA1298-Y                                      K              E                                    2



              Range               100~200           160~320
                                                                                                                                  D
            Marking                 IO                     IY                                    F                                     H                       J
                                                                                                                             G


                                                                                                                       Millimeter                   Millimeter
                                                                                                       REF.                            REF.
 PACKAGE INFORMATION                                                                                      A
                                                                                                                     Min.
                                                                                                                     2.80
                                                                                                                              Max.
                                                                                                                              3.00        G
                                                                                                                                                  Min.     Max.
                                                                                                                                                    0.10 REF.
                                                                                                          B          2.25     2.55        H         0.55 REF.
            Package                MPQ            LeaderSize                                              C          1.20     1.40        J       0.08     0.15
                                                                                                          D          0.90     1.15        K          0.5 REF.
             SOT-23                 3K               7' inch                                              E          1.80     2.00        L         0.95 TYP.
                                                                                                          F          0.30     0.50


                                                                                                                                  Collector



                                                                                                                 Base


                                                                                                                                   Emitter

 ABSOLUTE MAXIMUM RATINGS (TA = 25
