Image preview - the first page of the document



>> Download 2sa1586 documenatation <<

Text preview - extract from the document

                                                                                                      2SA1586
                                                                                                 -0.15 A, -50 V
                     Elektronische Bauelemente                                    PNP Silicon Plastic Encapsulated Transistor

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


 FEATURES                                                                                                                     SOT-323
      High DC Current Gain
      High Voltage and High Current                                                                               A
      Complementary to 2SC4116                                                                                    3
                                                                                                                      L

      Small Package                                                                                                                                          3

                                                                                                               Top View           C B
                                                                                                                                               1
                                                                                                           1              2

 APPLICATIONS                                                                                     K              E                                    2



    General Purpose Amplification
                                                                                                                                   D

                                                                                                  F                           G          H                       J


 CLASSIFICATION OF hFE                                                                                                  Millimeter                   Millimeter
                                                                                                       REF.                             REF.
                                                                                                                      Min.     Max.                Min.     Max.
        Product-Rank            2SA1586-O         2SA1586-Y             2SA1586-GR(G)                    A            1.80     2.20      G          0.100 REF.
                                                                                                         B            1.80     2.45      H          0.525 REF.
              Range               70~140            120~240                200~400                       C            1.15     1.35      J         0.08     0.25
                                                                                                         D            0.80     1.10      K           -        -
            Marking                 SO                     SY                    SG                      E            1.20     1.40      L          0.650 TYP.
                                                                                                         F            0.20     0.40



                                                                                                                                        Collector
 PACKAGE INFORMATION
            Package                MPQ            LeaderSize

            SOT-323                 3K               7' inch                                                              Base


                                                                                                                                        Emitter

 ABSOLUTE MAXIMUM RATINGS (TA = 25
