Image preview - the first page of the document



>> Download 2sc1162 documenatation <<

Text preview - extract from the document

                                                                                                        2SC1162
                                                                                                      2.5A , 35V
                     Elektronische Bauelemente                                            NPN Plastic Encapsulated Transistor

                                                           RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen & lead-free



 FEATURES                                                                                                                          TO-126
        Low frequency power amplifier


                                                                                                                                                  Emitter
                                                                                                                                                  Collector
                                                                                                                                                  Base
 CLASSIFICATION OF hFE (1)
        Product-Rank           2SC1162-B   2SC1162-C        2SC1162-D
                                                                                                                    A
                                                                                                                E                     B
             Range               60~120     100~200           160~320
                                                                                                        F
                                                                                                                                            C

                                                                                                                           N
                                                                                                        L                         H
                                                                                                                           M
                                                                                                        K                                   D

                                                                                                                                  J



                                                                              Collector                 G


                                                                                                                          Millimeter                Millimeter
                                                                                                        REF.                               REF.
                                                                                                                        Min.     Max.             Min.     Max.
                                                                                                            A           7.40     7.80       H     1.10     1.50
                                                                                                            B           2.50     2.90       J     0.45     0.60
                                                                Base                                        C           10.60    11.00      K     0.66     0.86
                                                                                                            D           15.30    15.70      L     2.10     2.30
                                                                                                            E           3.70     3.90       M     1.17     1.37
                                                                                                            F           3.90     4.10       N     3.00     3.20
                                                                              Emitter                       G             2.29 TYP.




 ABSOLUTE MAXIMUM RATINGS (TA = 25
