Image preview - the first page of the document



>> Download 2sc1654 documenatation <<

Text preview - extract from the document

                                                                                                                2SC1654
                                                                                                       0.05A , 180V
                     Elektronische Bauelemente                                                 NPN Epitaxial Planar Transistor

                                                                    RoHS Compliant Product
                                                      A suffix of "-C" specifies halogen & lead-free


                                                                                                                                           SOT-23
 FEATURE
           High Frequency Power Amplifier Application                                                                      A
           Power Switching Applications                                                                                        L
                                                                                                                           3
                                                                                                                                                                         3

                                                                                                                        Top View           C B
 CLASSIFICATION OF hFE(1)                                                                                           1              2
                                                                                                                                                          1



         Product-Rank          2SC1654-N5        2SC1654-N6         2SC1654-N7                          K                 E                                       2



             Range               90~180           135~270              200~400
                                                                                                                                            D
         Marking Code              N5               N6                       N7
                                                                                                        F                              G           H                         J


 PACKAGE INFORMATION                                                                                        REF.
                                                                                                                             Millimeter
                                                                                                                           Min.     Max.
                                                                                                                                                  REF.
                                                                                                                                                                Millimeter
                                                                                                                                                              Min.     Max.
                                                                                                                A          2.80     3.04           G          0.09     0.18
            Package                   MPQ              LeaderSize                                               B          2.10     2.55           H          0.45     0.60
                                                                                                                C          1.20     1.40           J          0.08     0.177
             SOT-23                     3K                  7' inch                                             D          0.89     1.15           K             0.6 REF.
                                                                                                                E          1.78     2.04           L          0.89     1.02
                                                                                                                F          0.30     0.50


                                                                                                                                             Collector




                                                                                                                               Base


                                                                                                                                                 Emitter
 ABSOLUTE MAXIMUM RATINGS (TA = 25
