Image preview - the first page of the document



>> Download 2sc1959 documenatation <<

Text preview - extract from the document

                                                                                                       2SC1959
                                                                                                  0.5 A , 35 V
                     Elektronische Bauelemente                                        NPN Plastic Encapsulated Transistor

                                                          RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen & lead-free


 FEATURES                                                                                                          TO-92
        Excellent hFE Linearity
        High Transition Frequency                                                                                                                 Millimeter
                                                                                                                                       REF.
                                                                                                                                               Min.      Max.
                                                                                                                                         A      4.40     4.70
                                                                                                                                         B      4.30     4.70
 CLASSIFICATION OF hFE                                                                                                                   C
                                                                                                                                         D
                                                                                                                                               12.70
                                                                                                                                                3.30
                                                                                                                                                           -
                                                                                                                                                         3.81
                                                                                                                                         E      0.36     0.56
        Product-Rank           2SC1959-O   2SC1959-Y       2SC1959-GR                                                                    F      0.36     0.51
                                                                                                                                         G        1.27 TYP.
                                                                                                                                         H      1.10       -
                   hFE(1)       70~140      120~240           200~400                                                                    J      2.42     2.66
        Range                                                                                                                            K      0.36     0.76
                   hFE(2)       25 (Min)    40 (Min)              -



 MARKING
                                                                                                                   Emitter
                                                                                                                   Collector
                            C1923                                                                                  Base
   hFE Rank                  031

                                                                                                           Collector




                                                                                              Base


                                                                                                            Emitter


 ABSOLUTE MAXIMUM RATINGS (TA = 25
