Image preview - the first page of the document



>> Download 2sc1923 documenatation <<

Text preview - extract from the document

                                                                                                     2SC1923
                                                                                                 0.02A , 40V
                     Elektronische Bauelemente                                       NPN Plastic Encapsulated Transistor

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


                                                                                                                      TO-92
 FEATURES
        General purpose switching and amplification.                                                             A              D

                                                                                                                         B


 CLASSIFICATION OF hFE
        Product-Rank           2SC1923-O   2SC1923-Y                                                    E                C       F

             Range               70~140     100~200

                                                                                                        G                 H
                                                                                                                                     Emitter
 MARKING                                                                                                                             Collector
                                                                                                                                     Base
                                                                                                                          J
                            C1923
    hFE Rank                O 031                                                                  REF.         Millimeter
                                                                                                             Min.      Max.
                                                                                                                                     REF.     Millimeter
                                                                                                                                            Min.     Max.
                                                                                                    A         4.40     4.70           F     0.30     0.51
                                                                                                    B         4.30     4.70           G       1.27 TYP.
                                                                                                    C        12.70       -            H     1.10     1.40
                            C1923                                                                   D         3.30     3.81           J     2.42     2.66
    hFE Rank                Y 031                                                                   E         0.36     0.56           K     0.36     0.76

                                                                                                                           Collector




                                                                                                            Base


                                                                                                                              Emitter

 ABSOLUTE MAXIMUM RATINGS (TA=25
