Image preview - the first page of the document



>> Download 2sc2859 documenatation <<

Text preview - extract from the document

                                                                                                           2SC2859
                                                                                                    0.5A , 35V
                     Elektronische Bauelemente                                          NPN Plastic-Encapsulate Transistor

                                                             RoHS Compliant Product
                                                   A suffix of "-C" specifies halogen & lead-free


                                                                                                                                     SOT-23
 FEATURES
         Excellent hFE Linearity                                                                                    A
         Switching Applications                                                                                          L
                                                                                                                    3
                                                                                                                                                               3

                                                                                                                 Top View            C B
 CLASSIFICATION OF hFE (1)                                                                                   1               2
                                                                                                                                                   1



    Product-Rank            2SC2859-O      2SC2859-Y      2SC2859-GR                                  K            E                                     2




         Range               70~140         120~240           200~400                                                                 D
        Marking                WO             WY                 WG                                   F                          G            H                    J

                                                                                                                          Millimeter                     Millimeter
 PACKAGE INFORMATION                                                                                       REF.
                                                                                                                        Min.     Max.
                                                                                                                                              REF.
                                                                                                                                                       Min.     Max.
                                                                                                            A           2.80      3.04         G       0.09     0.18
         Package                    MPQ            LeaderSize                                               B           2.10      2.55         H       0.45     0.60
                                                                                                            C           1.20      1.40         J       0.08     0.177
          SOT-23                      3K              7' inch                                               D
                                                                                                            E
                                                                                                                        0.89
                                                                                                                        1.78
                                                                                                                                  1.15
                                                                                                                                  2.04
                                                                                                                                               K
                                                                                                                                               L
                                                                                                                                                          0.6 REF.
                                                                                                                                                       0.89     1.02
                                                                                                            F           0.30      0.50


                                                                                                                                           Collector




                                                                                                                        Base


                                                                                                                                           Emitter


 ABSOLUTE MAXIMUM RATINGS (TA = 25
