Image preview - the first page of the document



>> Download dta123j_series documenatation <<

Text preview - extract from the document

                                                                     DTA123JE/DTA123JUA/DTA123JCA/
                                                                                DTA123JSA
             Elektronische Bauelemente                                 PNP Digital Transistors (Built-in Resistors)




       FEATURES
       * Built-in bias resistors enable the configuration of
         an inverter circuit without connecting input resistors
         (see equivalent circuit).
        * Only the on/off confitions need to be set for operation,
          making device design easy.
        * The bias resistors consis of thin-film resistors with
          compete isolation to allow negative biasing of the
          input. They also have the advantage of almost
          completely eliminating parasitic effects.




     PIN CONNENCTIONS AND MARKING

       DTA123JE                                                        DTA123JUA




         SOT-523             Abbreviated symbol: E32                    SOT-323
                                                                                    Abbreviated symbol: 132



         DTA123JSA
                                                                       DTA114ECA
                                                                       DTA123JCA




         TO-92S                                                        SOT-23      Abbreviated symbol: E32




  http://www.SeCoSGmbH.com                                                             Any changing of specification will not be informed individual

01-Jun-2002 Rev. A                                                                                                                     Page 1 of 2
                                                              DTA123JE/DTA123JUA/DTA123JCA/
                                                                         DTA123JSA
           Elektronische Bauelemente                               PNP Digital Transistors (Built-in Resistors)

    Absolute maximum ratings(Ta=25)
                                                                    Limits (DTA123J            )
             Parameter           Symbol                                                                                                 Unit
                                                      E             UA                      CA                          SA
    Supply voltage                      VCC                                    -50                                                        V
    Input voltage                       VIN                                  -12~+5                                                       V
                                        IO                                    -100
    Output current                                                                                                                       mA
                                     IC(MAX)                                  -100
    Power dissipation                   Pd            150                     200                                       300             mW
    Junction temperature                Tj                                    150
    Storage temperature               Tstg                                   -55~150

    Electrical characteristics (Ta=25)

         Parameter           Symbol            Min.         Typ      Max.        Unit                        Conditions
                              VI(off)                                 -0.5                             VCC=-5V, IO=-100
