Image preview - the first page of the document



>> Download dta143e_series documenatation <<

Text preview - extract from the document

                                                                     DTA143EE/DTA143EUA/DTA143ECA /
                                                                               DTA143ESA
             Elektronische Bauelemente                                 PNP Digital Transistors (Built-in Resistors)




       FEATURES
       * Built-in bias resistors enable the configuration of
         an inverter circuit without connecting input resistors
         (see equivalent circuit).
        * Only the on/off confitions need to be set for operation,
          making device design easy.
        * The bias resistors consis of thin-film resistors with
          compete isolation to allow negative biasing of the
          input. They also have the advantage of almost
          completely eliminating parasitic effects.




     PIN CONNENCTIONS AND MARKING


     DTA143EE                                                         DTC114EUA
                                                                      DTA143EUA




                                                                      SOT-323

     SOT-523            Abbreviated symbol: 13                                       Abbreviated symbol: 13




      DTA143ESA                                                       DTA143ECA




                                                                      SOT-23
         TO-92S
                                                                                   Abbreviated symbol: 13




  http://www.SeCoSGmbH.com                                                             Any changing of specification will not be informed individual

01-Jun-2002 Rev. A                                                                                                                     Page 1 of 2
                                                       DTA143EE/DTA143EUA/DTA143ECA /
                                                                 DTA143ESA
            Elektronische Bauelemente                        PNP Digital Transistors (Built-in Resistors)

     Absolute maximum ratings(Ta=25)
                                                               Limits (DTA143E )
           Parameter         Symbol                                                                                                  Unit
                                                 E            UA                          CA                        SA
        Supply voltage          VCC                                        -50                                                         V
         Input voltage          VIN                                       -30~10                                                       V
                                    IO                                     -100
        Output current                                                                                                               mA
                              IC(MAX)                                      -100
      Power dissipation         Pd              150                        200                                     300               mW
            Junction
                                    Tj                                     150
          temperature
    Storage temperature        Tstg                                      -55~150
     Electrical characteristics (Ta=25)
          Parameter          Symbol        Min.        Typ         Max.            Unit                      Conditions
                             VI(off)                             -0.5                                VCC=-5V ,IO=-100
