                                                                               DTA143TE / DTA143TUA/ DTA143TCA /
                                                                                           DTA143TSA
                     Elektronische Bauelemente                                       PNP Digital Transistors (Built-in Resistors)

                                                             RoHS Compliant Product
                                                   A suffix of "-C" specifies halogen & lead-free



 FEATURES
            Built-in bias resistors enable the configuration of
            an inverter circuit without connecting external
            input resistors (see equivalent circuit).                      DTA143TE (SOT-523)                    DTA143TUA (SOT-323)
            The bias resistors consist of thin-film resistors
            with complete isolation to allow positive biasing
            of the input. They also have the advantage of
            almost completely eliminating parasitic effects.
            Only the on/off conditions need to be set for
            operation, making device design easy.


 EQUIVALENT CIRCUIT                                                            Addreviated symbol93                  Addreviated symbol93
                                                                           DTA143TSA (TO-92S)                    DTA143TCA (SOT-23)




                                                                                                                     Addreviated symbol93
