Image preview - the first page of the document



>> Download dta143z_series documenatation <<

Text preview - extract from the document

                                                                     DTA143ZE/DTA143ZUA/DTA143ZCA/
                                                                               DTA143ZSA
             Elektronische Bauelemente                                 PNP Digital Transistors (Built-in Resistors)




       FEATURES
       * Built-in bias resistors enable the configuration of
         an inverter circuit without connecting input resistors
         (see equivalent circuit).
        * Only the on/off confitions need to be set for operation,
          making device design easy.
        * The bias resistors consis of thin-film resistors with
          compete isolation to allow negative biasing of the
          input. They also have the advantage of almost
          completely eliminating parasitic effects.




     PIN CONNENCTIONS AND MARKING

       DTA143ZE                                                        DTA143ZUA




                                                                       SOT-323      Abbreviated symbol: 113
       SOT-523            Abbreviated symbol: E13



       DTA143ZSA                                                       DTA143ZCA
                                                                       DTA114ECA




       TO-92S                                                          SOT-23         Abbreviated symbol: E13




  http://www.SeCoSGmbH.com                                                             Any changing of specification will not be informed individual

01-Jun-2002 Rev. A                                                                                                                     Page 1 of 2
                                                             DTA143ZE/DTA143ZUA/DTA143ZCA/
                                                                       DTA143ZSA
           Elektronische Bauelemente                              PNP Digital Transistors (Built-in Resistors)

    Absolute maximum ratings(Ta=25)
                                                                    Limits (DTA143Z )
            Parameter            Symbol                                                                                               Unit
                                                      E              UA                      CA                        SA
         Supply voltage                 VCC                                   -50                                                       V
          Input voltage                 VIN                                  -30~5                                                      V
                                         IO                                  -100
         Output current                                                                                                                mA
                                     IC(MAX)                                 -100
       Power dissipation                Pd            150                     200                                     300             mW
    Junction temperature                 Tj                                  150
     Storage temperature                Tstg                                -55~150
    Electrical characteristics (Ta=25)
          Parameter          Symbol            Min.         Typ     Max.        Unit                       Conditions
                              VI(off)                                -0.5                            VCC=-5V ,IO=-100
