Image preview - the first page of the document



>> Download dtc114y documenatation <<

Text preview - extract from the document

                                                                                     DTC114YE / DTC114YUA
                                                                                     DTC114YCA / DTC114YSA
                     Elektronische Bauelemente                                NPN Digital Transistors (Built-in Resistors)

                                                        RoHS Compliant Product
                                              A suffix of "-C" specifies halogen & lead-free



 FEATURES
                                                                              DTC114YE (SOT-523)                       DTC114YUA (SOT-323)
         Built-in bias resistors enable the configuration of an
         inverter circuit without connecting external input
         resistors (see equivalent circuit).
         The bias resistors consist of thin-film resistors with
         complete isolation to allow positive biasing of the
         input. They also have the advantage of almost
         completely eliminating parasitic effects.
         Only the on/off conditions need to be set for
         operation, making device design easy.                               Addreviated symbol64                     Addreviated symbol64
                                                                              DTC114YCA (SOT-23)                        DTA114YSA (TO-92S)

 EQUIVALENT CIRCUIT




                                                                             Addreviated symbol64




 ABSOLUTE MAXIMUM RATINGS (TA=25
