                                                                                                              MMBT3906
                                                                                                       -200 mA, -40 V
                     Elektronische Bauelemente                                               PNP Plastic Encapsulated Transistor

                                                                   RoHS Compliant Product
                                                       A suffix of "-C" specifies halogen and lead free



 FEATURES                                                                                                                        SOT-23
           Collector current capability IC=-200mA
           Collector-emitter voltage VCEO=-40V.


 APPLICATION                                                                                                     A
           General switching and amplification.                                                                      L
                                                                                                                 3
                                                                                                                                                                          3

                                                                                                              Top View              C B
 PACKAGING DIMENSION                                                                                                                              1
                                                                                                          1                 2

                                                                                                 K               E                                             2



                            Collector
                                                                                                                                       D

                                                                                                 F                              G            H                                J

             Base


                            Emitter

                                                                                                                         Millimeter                     Millimeter
                                                                                                          REF.                             REF.
                                                                                                                     Min.       Max.                  Min.         Max.
                                                                                                           A         2.80       3.00        G           0.10 REF.
                                                                                                           B         2.25       2.55        H           0.55 REF.
 MARKING                                                                                                   C         1.20       1.40        J         0.08         0.15
                                                                                                           D         0.90       1.15        K           0.5 REF.
                                                                                                           E         1.80       2.00        L           0.95 TYP.
                                                                                                           F         0.30       0.50




 ABSOLUTE MAXIMUM RATINGS (TA = 25
