Image preview - the first page of the document



>> Download mmbta06 documenatation <<

Text preview - extract from the document

                                                                                                      MMBTA06
                                                                                                  0.5A , 80V
                     Elektronische Bauelemente                                        NPN Plastic Encapsulated Transistor

                                                          RoHS Compliant Product
                                                 A suffix of "-C" specifies halogen & lead-free


 FEATURES                                                                                                                      SOT-23
        High Voltage Application
        Telephone Application                                                                                     A
                                                                                                                      L
        Complementary to MMBTA56                                                                                  3
                                                                                                                                                              3

                                                                                                               Top View           C B
                                                                                                                                                1
 MARKING                                                                                                   1              2

                                                                                                  K              E                                     2

         1GM
                                                                                                                                   D

 PACKAGE INFORMATION                                                                              F                           G          H                        J

            Package                 MPQ          Leader Size
                                                                                     Collector        REF.
                                                                                                                     Millimeter
                                                                                                                                         REF.
                                                                                                                                                      Millimeter
             SOT-23                 3K                7 inch                                           A
                                                                                                                   Min.
                                                                                                                   2.80
                                                                                                                            Max.
                                                                                                                            3.04          G
                                                                                                                                                    Min.
                                                                                                                                                    0.09
                                                                                                                                                             Max.
                                                                                                                                                              0.18
                                                                                                       B           2.10     2.55          H         0.45      0.60
                                                                                                       C           1.20     1.40          J         0.08     0.177
                                                                                                       D           0.89     1.15          K            0.6 REF.
                                                                                                       E           1.78     2.04          L         0.89      1.02
                                                                          Base                         F           0.30     0.50



                                                                                      Emitter




 ABSOLUTE MAXIMUM RATINGS (TA=25
