Image preview - the first page of the document
>> Download smun5311dw_series documenatation <<Text preview - extract from the document SMUN5311DW Series
NPN / PNP
Elektronische Bauelemente Digital Small Signal Transistors
RoHS Compliant Product
A suffix of "-C" indicates halogen-free.
DESCRIPTION SOT-363
The Bias Resistor Transistor (BRT) contains a single transistor with a monolithic
bias network consisting of two resistors; a series base resistor and a base-emitter
resistor. These digital transistors are designed to replace a single device and its A
external resistor bias network. The BRT eliminates these individual components by E
L
integrating them into a single device. In the SMUN5311DW series, two
complementary BRT devices are housed in the SOT-363 package which is ideal
for low power surface mount applications where board space is at a premium.
B
FEATURE
Simplifies circuit design F C H
Reduces board space
DG K J
Reduces component count
Available in 8 mm, 7 inch/3000 unit tape and reel
The devices are Pb-Free
6 5 4 Millimeter Millimeter
REF. REF.
Min. Max. Min. Max.
A 2.00 2.20 G 0.100 REF.
R1 B 2.15 2.45 H 0.525 REF.
Q2 R2 C 1.15 1.35 J 0.08 0.15
D 0.90 1.10 K 8
