                                                                                                  SMG2343PE
                                                                                           -3.6 A, -30 V, RDS(ON) 57 m
                     Elektronische Bauelemente                                          P-Channel Enhancement MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free

                                                                                                                                    SC-59
 DESCRIPTION
 These miniature surface mount MOSFETs utilize a high cell density trench process
 to provide low RDS(on) and to ensure minimal power loss and heat dissipation.
 Typical applications are DC-DC converters and power management in
 portable and battery-powered products such as computers, printers,                                                     A
 PCMCIA cards, cellular and cordless telephones.                                                                        3
                                                                                                                            L

                                                                                                                                                                   3

                                                                                                                    Top View            C B
                                                                                                                                                     1

 FEATURES                                                                                               K
                                                                                                                1

                                                                                                                        E
                                                                                                                                2
                                                                                                                                                              2

             Low RDS(on) provides higher efficiency and extends battery life.
             Low thermal impedance copper leadframe SC-59 saves board                                                                    D
             space.                                                                                     F                           G          H                       J
             Fast switching speed.
             High performance trench technology.
                                                                                                                             Millimeter                   Millimeter
                                                                                                              REF.                            REF.
                                                                                                                            Min.   Max.                  Min.   Max.
 PRODUCT SUMMARY                                                                                                    A       2.70    3.10       G          0.10 REF.
                                                                                                                    B       2.25    3.00       H          0.40 REF.
         PRODUCT SUMMARY                                                                                            C       1.30    1.70       J         0.10   0.20
                                                                                                                    D       1.00    1.40       K         0.45   0.55
            VDS(V)           RDS(on) (m               ID(A)                                                         E       1.70    2.30       L         0.85   1.15
                            57@VGS= -10V               -3.6                                                         F       0.35    0.50
             -30
                            89@VGS= -4.5V              -2.8


 PACKAGE INFORMATION
             Package                   MPQ                    LeaderSize                           ESD
                                                                                             Protection Diode
              SC-59                     3K                      7' inch                            2KV




   ABSOLUTE MAXIMUM RATINGS AND THERMAL DATA(TA = 25
