Image preview - the first page of the document
>> Download smg2342ne documenatation <<
Text preview - extract from the document
SMG2342NE
5.2 A, 40 V, RDS(ON) 86 m
Elektronische Bauelemente N-Channel Enhancement MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
SC-59
DESCRIPTION
These miniature surface mount MOSFETs utilize a
high cell density trench process to provide low RDS(on) and
to ensure minimal power loss and heat dissipation. Typical A
L
applications are DC-DC converters and power management 3
3
in portable and battery-powered products such as Top View C B
computers, printers, PCMCIA cards, cellular and cordless 1 2
1
telephones. K E 2
D
FEATURES F G H J
Low RDS(on) provides higher efficiency and extends
battery life.
Low thermal impedance copper leadframe SC-59
saves board space.
Fast switching speed.
High performance trench technology. REF.
Millimeter
Min. Max.
REF.
Millimeter
Min. Max.
A 2.70 3.10 G 0.10 REF.
B 2.25 3.00 H 0.40 REF.
C 1.30 1.70 J 0.10 0.20
PACKAGE INFORMATION D 1.00 1.40 K 0.45 0.55
E 1.70 2.30 L 0.85 1.15
F 0.35 0.50
Package MPQ LeaderSize
SC-59 3K 7' inch
ESD
Protection
Diode
2KV
ABSOLUTE MAXIMUM RATINGS (TA = 25◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
