Image preview - the first page of the document



>> Download smg2390n documenatation <<

Text preview - extract from the document

                                                                                                         SMG2390N
                                                                                     N-Channel Enhancement Mode Mos.FET
                     Elektronische Bauelemente                                            1.1 A, 150 V, RDS(ON) 0.700

                                                          RoHS Compliant Product
                                              A suffix of "-C" specifies halogen and lead-free
 DESCRIPTION
      These miniature surface mount MOSFETs utilize a High Cell Density
                                                                                                                               SC-59
      trench process to provide Low RDS(on) and to ensure minimal power                                           A
      loss and heat dissipation. Typical applications are DC-DC converters                                            L
                                                                                                                  3
      and power management in portable and battery-powered products                                                                                           3


      such as computers, printers, PCMCIA cards, cellular and cordless                                         Top View           C B
                                                                                                                                               1
      telephones.                                                                                          1              2

                                                                                                     K           E                                     2




 FEATURES                                                                                                                          D
             Low RDS(on) provides higher efficiency and extends battery life.
                                                                                                     F                        G          H                        J
             Low thermal impedance copper leadframe SC-59 saves
             board space.
             Fast switching speed.
             High performance trench technology.
                                                                                                                     Millimeter                      Millimeter
                                                                                                         REF.                           REF.
                                                                                                                   Min.     Max.                   Min.     Max.
 PRODUCT SUMMARY                                                                                          A
                                                                                                          B
                                                                                                                   2.70
                                                                                                                   2.25
                                                                                                                            3.10
                                                                                                                            3.00
                                                                                                                                         G
                                                                                                                                         H
                                                                                                                                                     0.10 REF.
                                                                                                                                                     0.40 REF.
                                                                                                          C        1.30     1.70         J         0.10     0.20
         PRODUCT SUMMARY                                                                                  D        1.00     1.40         K         0.45     0.55

         VDS(V)                RDS(on) (             ID(A)                                                E        1.70     2.30         L         0.85     1.15
                                                                                                          F        0.35     0.50
                            0.700@VGS= 10V            1.1
           150
                            1.200@VGS= 5.5V           0.8




 ABSOLUTE MAXIMUM RATINGS(TA=25
