Image preview - the first page of the document



>> Download smg2398n documenatation <<

Text preview - extract from the document

                                                                                                         SMG2398N
                                                                                         2.2 A, 60 V, RDS(ON) 194 m
                     Elektronische Bauelemente                                      N-Channel Enhancement Mode Mos.FET

                                                         RoHS Compliant Product
                                             A suffix of "-C" specifies halogen and lead-free
 DESCRIPTION
      These miniature surface mount MOSFETs utilize High Cell Density
                                                                                                                               SC-59
      process. Low RDS(on) assures minimal power loss and conserves energy,                                       A
      making this device ideal for use in power management circuitry. Typical                                         L
                                                                                                                  3
      applications are power switch, power management in portable and battery-                                                                                3


      powered products such as computers, printers, PCMCIA cards, cellular                                     Top View           C B
                                                                                                                                               1
      and cordless telephones.                                                                             1              2

                                                                                                     K           E                                     2




 FEATURES                                                                                                                          D
             Low RDS(on) provides higher efficiency and extends battery life.
                                                                                                     F                        G          H                        J
             Low gate charge
             Fast switching
             Miniature SC-59 surface mount package saves board space.

                                                                                                                     Millimeter                      Millimeter
 PRODUCT SUMMARY                                                                                         REF.
                                                                                                                   Min.     Max.
                                                                                                                                        REF.
                                                                                                                                                   Min.     Max.
                                                                                                          A        2.70     3.10         G           0.10 REF.
             SMG2398N                                                                                     B        2.25     3.00         H           0.40 REF.
                                                                                                          C        1.30     1.70         J         0.10     0.20
         VDS(V)              RDS(on) (m             ID(A)                                                 D        1.00     1.40         K         0.45     0.55
                                                                                                          E        1.70     2.30         L         0.85     1.15
                            194@VGS= 10V             2.2
            60                                                                                            F        0.35     0.50
                            273@VGS= 4.5V            1.8


 PACKAGE INFORMATION
             Package                MPQ              LeaderSize
                 SC-59               3K                  7' inch


 ABSOLUTE MAXIMUM RATINGS(TA=25
