Image preview - the first page of the document



>> Download smg2306ne documenatation <<

Text preview - extract from the document

                                                                                                        SMG2306NE
                                                                                        3.5A , 30V , RDS(ON) 58 m
                     Elektronische Bauelemente                                     N-Channel Enhancement Mode Mos.FET

                                                        RoHS Compliant Product
                                            A suffix of "-C" specifies halogen and lead-free


 DESCRIPTION                                                                                                                SC-59
          These miniature surface mount MOSFETs utilize                                                         A
   High Cell Density process. Low RDS(on) assures                                                                   L
                                                                                                                3
   minimal power loss and conserves energy, making                                                                                                          3


   this device ideal for use in power management                                                            Top View            C B
   circuitry.
                                                                                                                                                1
                                                                                                        1               2

                                                                                               K                E                                     2




 FEATURES                                                                                                                        D
        Low RDS(on) provides higher efficiency and
                                                                                               F                            G          H                        J
        extends battery life.
        Low gate charge
        Fast switching                                                                                  REF.          Millimeter        REF.          Millimeter
        Miniature SC-59 surface mount package                                                               A
                                                                                                                    Min.
                                                                                                                    2.70
                                                                                                                             Max.
                                                                                                                             3.10           G
                                                                                                                                                    Min.     Max.
                                                                                                                                                      0.10 REF.
        saves board space.                                                                                  B       2.25     3.00           H         0.40 REF.
                                                                                                            C       1.30     1.70           J       0.10     0.20
                                                                                                            D       1.00     1.40           K       0.45     0.55
 APPLICATION                                                                                                E       1.70     2.30           L       0.85     1.15
                                                                                                            F       0.35     0.50
          PWMDC-DC converters, power management in
   portable and battery-powered products such as computers,
   printers, battery charger, telecommunication power system,
   and telephones power system.

 PACKAGE INFORMATION                                                                                      ESD
                                                                                                    Protection Diode
             Package                MPQ            Leader Size                                            2KV

              SC-59                 3K                 7' inch




 ABSOLUTE MAXIMUM RATINGS (TA=25
