Image preview - the first page of the document



>> Download smg2310a documenatation <<

Text preview - extract from the document

                                                                                                         SMG2310A
                                                                                   N-Ch Enhancement Mode Power MOSFET
                  Elektronische Bauelemente                                              5.0 A, 60 V, RDS(ON)=115 m

                                                          sRoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free                                     SC-59
DESCRIPTIONS
     The SMG2310A utilized advanced processing techniques to achieve the                                           A
                                                                                                                       L
     lowest possible on-resistance, extremely efficient and cost-effectiveness                                     3
                                                                                                                                                             3
     device. The SMG2310A is universally used for all commercial-industrial                                    Top View            C B
     applications.                                                                                                                               1
                                                                                                           1               2

                                                                                                     K             E                                   2



FEATURES
                                                                                                                                    D
          Simple Drive Requirement,
          Small Package Outline                                                                      F                         G         H                       J
          Super High Density Cell Design for Extremely Low RDS(ON)
                                                                                                           REF.          Millimeter        REF.        Millimeter
                                                                                                                       Min.     Max.                 Min.     Max.
                                                                                                               A       2.70     3.10         G         0.10 REF.
                                                                                                               B       2.25     3.00         H         0.40 REF.
MARKING CODE                           N-Channel Drain                                                         C       1.30     1.70         J       0.10     0.20

                                                     3
                                                                                                               D       1.00     1.40         K       0.45     0.55
          3                                                                                                    E       1.70     2.30         L       0.85     1.15
          D                                                                                                    F       0.35     0.50


      2310A                               1
                                        Gate

                                                     2
      1       2
      G       S
                                                  Source

ABSOLUTE MAXIMUM RATINGS

                         PARAMETER                                  SYMBOL                   RATINGS                                       UNIT
     Drain-Source Voltage                                              VDS                           60                                      V
     Gate-Source Voltage                                               VGS
