Image preview - the first page of the document



>> Download smg2314ne documenatation <<

Text preview - extract from the document

                                                                                                      SMG2314NE
                                                                                          4 A, 20 V, RDS(ON) 32 m
                     Elektronische Bauelemente                                      N-Channel Enhancement Mode Mos.FET

                                                         RoHS Compliant Product
                                             A suffix of "-C" specifies halogen and lead-free



 DESCRIPTION
           These miniature surface mount MOSFETs utilize High Cell
                                                                                                                              SC-59
      Density process. Low RDS(on) assures minimal power loss and                                                 A
      conserves energy, making this device ideal for use in power                                                     L
                                                                                                                  3
      management circuitry. Typical applications are PWMDC-DC                                                                                                 3


      converters, power management in portable and battery-powered                                             Top View           C B
                                                                                                                                               1
      products such as computers, printers, battery charger,                                               1              2


      telecommunication power system, and telephones power system.                                   K           E                                     2




                                                                                                                                   D
 FEATURES
                                                                                                     F                        G          H                        J
             Low RDS(on) provides higher efficiency and extends
             battery life.
             Miniature SC-59 surface mount package saves
             board space.
             High power and current handling capability.                                                 REF.
                                                                                                                     Millimeter
                                                                                                                                        REF.
                                                                                                                                                     Millimeter
                                                                                                                   Min.     Max.                   Min.     Max.
             MLow side high current DC-DC Converter applications                                          A        2.70     3.10         G           0.10 REF.
                                                                                                          B        2.25     3.00         H           0.40 REF.
                                                                                                          C        1.30     1.70         J         0.10     0.20
                                                                                                          D        1.00     1.40         K         0.45     0.55
                                                                                                          E        1.70     2.30         L         0.85     1.15
                                                                                                          F        0.35     0.50
 PACKAGE INFORMATION
             Package                MPQ              LeaderSize
                 SC-59               3K                  7' inch

                                                                                               ESD
                                                                                         Protection Diode
                                                                                               2KV


 ABSOLUTE MAXIMUM RATINGS(TA=25
