Image preview - the first page of the document
>> Download smg2319p documenatation <<Text preview - extract from the document SMG2319P
-2.1A , -30V , RDS(ON) 200 m
Elektronische Bauelemente P-Channel Enhancement MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DESCRIPTION SC-59
The miniature surface mount MOSFETs utilize
high cell density process. Low RDS(on) assures minimal A
power loss and conserves energy, making this L
3
device ideal for use in power management circuitry. 3
Top View C B
1
1 2
K E
FEATURES 2
Low RDS(on) provides higher efficiency and extends D
battery life.
F G H J
Fast Switch.
Low Gate Charge. Millimeter Millimeter
REF. REF.
Miniature SC-59 Surface Mount Package Saves Min. Max. Min. Max.
A 2.70 3.10 G 0.10 REF.
Board Space. B 2.25 3.00 H 0.40 REF.
C 1.30 1.70 J 0.10 0.20
D 1.00 1.40 K 0.45 0.55
E 1.70 2.30 L 0.85 1.15
APPLICATION F 0.35 0.50
Voltage control small signal switch, power management
in portable and battery-powered products such as computer
portable electronics and other battery power application.
1
PACKAGE INFORMATION 3
Package MPQ Leader Size 2
SC-59 3K 7' inch
MAXIMUM RATINGS (TA = 25
