Image preview - the first page of the document
>> Download smg2327p documenatation <<
Text preview - extract from the document
SMG2327P
-3.6 A, -20 V, RDS(ON) 52 m
Elektronische Bauelemente P-Channel Enhancement MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
DESCRIPTION SC-59
The miniature surface mount MOSFETs utilize high
A
cell density process.Low RDS(on) assures minimal power L
loss and conserves energy, making this device ideal for 3
3
use in power management circuitry. Top View C B
1
1 2
K E 2
FEATURES
Low RDS(on) provides higher efficiency and extends D
battery life.
F G H J
Miniature SC-59 surface mount package saves
board space.
Fast switching speed. REF. Millimeter REF. Millimeter
High performance trench technology. A
Min.
2.70
Max.
3.10 G
Min. Max.
0.10 REF.
B 2.25 3.00 H 0.40 REF.
C 1.30 1.70 J 0.10 0.20
D 1.00 1.40 K 0.45 0.55
APPLICATION E 1.70 2.30 L 0.85 1.15
F 0.35 0.50
DC-DC converters, power management in
portable and battery-powered products such as
computers, printers, PCMCIA cards, cellular and
cordless telephones.
PACKAGE INFORMATION
Package MPQ Leader Size
SC-59 3K 7 inch
ABSOLUTE MAXIMUM RATINGS (TA=25◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
