                                                                                                      SMG2328NE
                                                                                            6.3 A, 20 V, RDS(ON) 22 m
                     Elektronische Bauelemente                                          N-Channel Enhancement MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free



                                                                                                                                          SC-59
 DESCRIPTION
          These miniature surface mount MOSFETs utilize a
     high cell density trench process to provide low RDS(on) and to                                                          A
     ensure minimal power loss and heat dissipation. Typical                                                                      L

     applications are DC-DC converters and power management                                                                  3
                                                                                                                                                                         3


     in portable and battery-powered products such as computers,                                                          Top View            C B
     printers,PCMCIA cards, cellular and cordless telephones.                                                         1               2
                                                                                                                                                           1


                                                                                                               K            E                                       2




 FEATURES                                                                                                                                      D

           Low RDS(on) provides higher efficiency and extends battery life.                                    F                          G           H                      J

           Low thermal impedance copper leadframe SC-59 saves board
           space.
           Fast switching speed.                                                                                    REF.
                                                                                                                                  Millimeter
                                                                                                                                                    REF.
                                                                                                                                                            Millimeter
                                                                                                                                 Min.   Max.               Min.   Max.
           High performance trench technology.                                                                        A          2.70    3.10        G      0.10 REF.
                                                                                                                      B          2.25    3.00        H      0.40 REF.
                                                                                                                      C          1.30    1.70        J     0.10   0.20
                                                                                                                      D          1.00    1.40        K     0.45   0.55
 PACKAGE INFORMATION                                                                                                  E          1.70    2.30        L     0.85   1.15
                                                                                                                      F          0.35    0.50
             Package                MPQ               LeaderSize
               SC-59                 3K                  7' inch




                                                                                                   ESD
                                                                                                 Protection
                                                                                                   Diode
                                                                                                    2KV




   ABSOLUTE MAXIMUM RATINGS (TA = 25
