Image preview - the first page of the document



>> Download smg2329p documenatation <<

Text preview - extract from the document

                                                                                                 SMG2329P
                                                                                           -2.5 A, -30 V, RDS(ON) 0.112
                     Elektronische Bauelemente                                          P-Channel Enhancement MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free




                                                                                                                               SC-59
 DESCRIPTION
 The miniature surface mount MOSFETs utilize a high cell density trench process
 To provide low RDS(on) and to ensure minimal power loss and heat dissipation.
 Typical applications are DC-DC converters and power management in
 portable and battery-powered products such as computers, printers,
 PCMCIA cards, cellular and cordless telephones.                                                                   A
                                                                                                                       L
                                                                                                                   3
                                                                                                                                                                  3

 FEATURES                                                                                                     Top View             C B
             Low RDS(on) provides higher efficiency and extends battery life.                             1                2
                                                                                                                                                1


             Low thermal impedance copper leadframe SC-59 saves board                            K              E                                         2


             space.
             Fast switching speed.                                                                                                  D
             High performance trench technology.                                                                                          H                           J
                                                                                                 F                             G


                                                                                                                        Millimeter                   Millimeter
                                                                                                              REF.                       REF.
 PRODUCT SUMMARY                                                                                               A
                                                                                                                       Min.
                                                                                                                       2.70
                                                                                                                              Max.
                                                                                                                               3.10       G
                                                                                                                                                    Min.   Max.
                                                                                                                                                     0.10 REF.
                                                                                                               B       2.25    3.00       H          0.40 REF.
         PRODUCT SUMMARY                                                                                       C       1.30    1.70       J         0.10   0.20
                                                                                                               D       1.00    1.40       K         0.45   0.55
            VDS(V)             RDS(on) (              ID(A)                                                    E       1.70    2.30       L         0.85   1.15
                            0.112@VGS= -10V            -2.5                                                    F       0.35    0.50
             -30
                            0.172@VGS= -4.5V           -2.0


 PACKAGE INFORMATION
             Package                   MPQ                    LeaderSize
              SC-59                     3K                      7' inch



   ABSOLUTE MAXIMUM RATINGS AND THERMAL DATA(TA = 25
