Image preview - the first page of the document



>> Download smg2330n documenatation <<

Text preview - extract from the document

                                                                                                 SMG2330N
                                                                                             5.2A, 30V, RDS(ON) 32m
                     Elektronische Bauelemente                                           N-Channel Enhancement MOSFET

                                                          RoHS Compliant Product
                                                A suffix of "-C" specifies halogen & lead-free


 DESCRIPTION                                                                                                                        SC-59
         These miniature surface mount MOSFETs utilize High
   Cell Density process. Low RDS(on) assures minimal power                                                        A
                                                                                                                        L
   loss and conserves energy, making this device ideal for                                                          3
   use in power management circuitry. Typical applications are                                                                                                  3


   PWMDC-DC converters, power management in portable                                                           Top View             C B
                                                                                                                                                   1
   and battery-powered products such as computers, printers,                                               1                2

   battery charger, telecommunication power system, and                                          K               E                                        2


   telephones power system.
                                                                                                                                     D

 FEATURES                                                                                        F                              G             H                     J
         Low RDS(on) Provides Higher Efficiency and Extends Battery Life
         Miniature SOT-23 Surface Mount Package Saves Board Space                                    REF.
                                                                                                                  Millimeter
                                                                                                                                      REF.
                                                                                                                                                   Millimeter
                                                                                                                 Min.   Max.                      Min.   Max.
         High power and current handling capability                                                    A         2.70    3.10             G        0.10 REF.
                                                                                                       B         2.25    3.00             H        0.40 REF.
         Low side high current DC-DC Converter applications                                            C         1.30    1.70             J       0.10   0.20
                                                                                                       D         1.00    1.40             K       0.45   0.55
                                                                                                       E         1.70    2.30             L       0.85   1.15
                                                                                                       F         0.35    0.50


 PACKAGE INFORMATION
             Package                     MPQ          Leader Size
               SC-59                     3K               7 inch




 ABSOLUTE MAXIMUM RATINGS (TA=25
